UDAAN AJAX Self-Loading Concrete Mixer
UDAAN is a powerful self-loading concrete mixer engineered for speed, efficiency, and ease. Ideal for urban construction sites and fast-paced projects.
Technical Specifications
Drum Capacity
0.8 cu.m
Drum Rotation Speed Max
18 rpm
Engine
18.5 kW @ 2200 rpm, CEV Stage 5
Bucket Capacity
225 L
Water Tank Capacity
45 L
Fuel Tank Capacity
25 L
Vehicle Speed
0–13 km/h
Tyres
10.0 / 75 x 15.3 Heavy Duty
Water Pump
80–90 L/min
Hydraulic Tank
45 L
Gradeability
14.5 Degree (Laden)
Variant
Non-swivel
Key Features & Benefits
- Self-loading design reduces manual labor and saves time on site.
- Compact size ideal for urban and narrow construction sites.
- Consistent and high-quality concrete output with optimized drum and spiral blades.
- Heavy-duty axle ensures superior load-bearing capacity.
- Bolted cabin design for structural integrity and easy maintenance.
- Pressure transducer system for precise water control.
- Advanced 4WD for maneuverability on rough terrain.
- Self-priming water pump ensures uninterrupted mixing and cleaning.
Frequently Asked Questions (FAQ)
1. What is UDAAN AJAX Self-Loading Concrete Mixer?
UDAAN AJAX is a compact self-loading concrete mixer designed for fast and efficient concreting on urban and narrow construction sites. It combines loading, mixing, and transporting in one machine.
2. What is the drum capacity of UDAAN AJAX?
The drum capacity is 0.8 cubic meters, suitable for small to medium construction projects.
3. What type of engine does it use?
UDAAN AJAX is powered by an 18.5 kW engine compliant with CE Stage 5 standards, ensuring efficient performance and low emissions.
4. How fast can UDAAN AJAX move on site?
The vehicle has a top speed of 13 km/h, allowing it to maneuver safely on urban construction sites.
5. What are the key benefits of using UDAAN AJAX?
Key benefits include self-loading operation, compact size for urban areas, consistent concrete output, easy maintenance, heavy-duty construction, and CE-compliant engine for safe and efficient use.
6. Is UDAAN AJAX suitable for narrow urban sites?
Yes. UDAAN AJAX is specifically designed for narrow and urban construction sites where space is limited.
7. What maintenance is required for UDAAN AJAX?
Regular maintenance includes checking engine oil, hydraulic system, drum blades, water pump, and tires. The machine is designed for easy access to all serviceable parts.
8. Can UDAAN AJAX be used for large construction projects?
UDAAN AJAX is ideal for small to medium projects. For very large-scale projects, multiple units or larger concrete batching solutions may be recommended.
9. How do I request a quote for UDAAN AJAX?
You can request a quote directly from this page by clicking the Request a Quote button and filling the form. Our B2B team will contact you within 4 business hours.
